Adjustable Props

Get a Price/Quote

MOQ : 1 Unit

Adjustable Props Specification

Pin
Cast iron or steel prop pin

Sleeve size
Adjusts to suit extension mechanism

Weight
12 - 18 kg (varies per prop size)

Constitute
Mild steel tubes and high strength fittings

Technique
ERW (Electric Resistance Welded) steel tubes

Features
Durable, Corrosion resistant, Reusable, Easy adjustment

Prop Head
Flat (standard) or U-head (optional)

Color
Blue / Red / Customized

Product Type
Adjustable Steel Scaffolding Prop

Material
High grade Mild Steel

Components
Inner tube, Outer tube, Threaded collar, Prop nut, Base plate, Head plate, Lock pin, Prop sleeve

Diameter
48 mm (Inner tube), 60 mm (Outer tube)

Width
As per standard adjustable tube widths

Length
Minimum 1.6 m to Maximum 3.0 m (custom sizes available)

Height
Adjustable as per site requirements

Thickness
2.0 mm - 3.5 mm (Inner/Outer tube)

Platform Loading Capacity
1.5 to 3 Tons (Varies by model and extension length)

Surface Treatment
Hot Dip Galvanized or Powder Coated

Application
Construction support, Slab and beam formwork, Scaffolding works

Size
Standard: 2m x 3.5m (custom sizes available)

Operating Temperature
-10C to 60C

Base Plate Size
150 mm x 150 mm

Life Cycle
Multiple uses in construction

Compliance
Meets ISI and international scaffolding standards

Adjustment Method
Threaded Collar & Pin Locks

Top Plate Size
120 mm x 120 mm

Standard Packaging
Bundle / as per requirement

Adjustable Props Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Week

Delivery Time
1 Week

About Adjustable Props

We are the most trusted and unrivaled name in manufacturing and supplying the paramount quality array of Adjustable Props. The provided props are manufactured under the stern guidance of our highly skilled professionals with the use of optimum quality components at our well established manufacturing unit. Highly demanded in construction, maintenance, automobile and other engineering applications for bridging and supporting purpose, these props are available in several lengths and dimensions. Moreover, clients can avail the provided Adjustable Props at highly competitive prices from us.

Salient Features:

Strong structure
Perfect finish
Resistant to corrosion
Excellent durability

Technical specification

Specification
NUT	Malleable casting
CHAIN	12g MS
TOP PLATE	150 x 150 or 100 x 300 x 5 m.m Thick Plate
BASE PLATE	150 x 150 x 6 m.m.

PROP SIZE	HEIGHT(mtr.)
	Closed	Extended
CP-1	1.5	2.75
CP-2	2.0	3.25
CP-3	2.0	3.75
CP-4	3.0	4.75

Superior Load Performance

Engineered to support between 1.5 and 3 tons, these adjustable props can sustain various platforms, slab, and beam structures during use. Their robust ERW steel construction and high-grade fittings make them suitable even for extensive commercial projects.

Seamless Adjustability and Versatility

With a threaded collar and pin lock adjustment mechanism, the props cater to varying site height requirements, extending from 1.6 to 3.0 meters. The mechanism allows for quick and secure alterations, simplifying the formwork process for builders and contractors.

Compliance and Durability Guaranteed

Manufactured following ISI and international scaffolding standards, these props assure safety and reliability on site. Their corrosion-resistant surface treatment further extends product life, ensuring they remain effective and reusable over multiple construction cycles.

FAQs of Adjustable Props:

Q: How do the adjustable props function in construction applications?

A: The adjustable props utilize a threaded collar and pin lock system, allowing users to extend or reduce their length as needed for supporting slabs, beams, and scaffolding. Simply rotate the collar to the desired height, insert the pin lock for secure positioning, and the prop is ready for load-bearing tasks.

Q: What materials and finishes are used to ensure the props longevity and strength?

A: Each prop is manufactured with high-grade mild steel tubes using ERW technology for superior durability. The components feature either a hot dip galvanized or powder-coated surface to provide enhanced corrosion resistance, making them ideal for repeated use on site.

Q: Where can these adjustable props be deployed and for what types of projects?

A: These props are designed for use in a broad range of construction environments, including residential, commercial, and infrastructure projects across India. Applications include temporary support for slab and beam formwork, scaffolding, and as part of staging systems during building erection.

Q: What is the process for adjusting and securing the props at your required height?

A: To adjust the prop, simply turn the threaded collar to raise or lower the upper tube until the desired height is achieved. Insert the lock pin through the aligned holes and fasten the prop nut for additional security. This process ensures both precision and stability during load-bearing operations.

Q: What benefits do these adjustable props offer compared to traditional support systems?

A: They are reusable, feature easy and rapid adjustment, and comply with both ISI and international standards. Their corrosion-resistant coating, robust load capacity, and flexibility for custom sizing make them a practical and cost-effective long-term solution for construction support needs.

Q: When should the props be inspected or replaced?

A: It is recommended to inspect the props before each use for signs of wear, deformation, or corrosion. With proper maintenance and handling, these props have an extended life cycle and can be used across multiple projects, but damaged components should be replaced immediately to maintain safety standards.
